MEDER HM12-1B83-03 HM Series Reed Relay
Mobicon-Remote Electronic Pte Ltd
Mobicon-Remote Electronic Pte Ltd Is An Electronic Components Distributor Company Which Is Located In Singapore.
Equiry Form
SPECIFICATIONS
Mounting Type Through Hole
Coil Voltage 12VDC
Contact Form SPST-NC (1 Form B)
Contact Rating (Current) 3 A
Switching Voltage 7500VAC, 7500VDC - Max
Coil Current 48 mA
Coil Type Non Latching
Features -
Termination Style PC Pin
Seal Rating -
Must Operate Voltage 9 VDC
Must Release Voltage 1 VDC
Operate Time 3 ms
Release Time 1.5 ms
Operating Temperature -20°C ~ 70°C
Contact Material -
Coil Resistance 250 Ohms
