MEDER SIL24-1A72-71M Series Reed Relay
Mobicon-Remote Electronic Pte Ltd
Mobicon-Remote Electronic Pte Ltd Is An Electronic Components Distributor Company Which Is Located In Singapore.
Equiry Form
SPECIFICATIONS
Automotive No
Automotive No
PPAP No
Type Dry
Contact Arrangement SPST-NO
DC Coil Voltage (V) 24
Coil Current (mA) 12
Coil Resistance (Ohm) 2K
Maximum Contact Resistance (MOhm) 150
Insulation Resistance (Ohm) 10G(Min)|100G(Min)
Maximum Pick-Up Voltage 16.8VDC
Maximum AC Switching Voltage (V) 200
Maximum DC Switching Voltage (V) 200
Maximum Switching Current (A) 1
Minimum Dropout Voltage 3.6VDC
Maximum Carry Current (A) 1.25
Isolation Across Contacts 250VDC(Min)
Isolation Across Coil and Contacts 1.5KVAC(Min)
Maximum Switching Power 15W
Operate Time (ms) 0.5
Release Time (ms) 0.1
LED Indicator No
Push to Test Button No
Coil Suppression Diode No
Mounting Through Hole
Termination Style PC Pin
Number of Terminals 4
Relay Construction Non-Latching
Minimum Operating Temperature (°C) -20
Maximum Operating Temperature (°C) 70
Product Length (mm) 20.6
Product Depth (mm) 5.9
Product Height (mm) 8.3
